Dual Output On/Off-Grid Solar Inverter 4.2kw 6.2kw 10.2kw Hybrid Inverter with Dual PV Input Solar Charge Controller – AliExpress – Color : 10.2Kw with wifi

Maximum PV Input Power: 6200W/6500W/10200W
Rated Output Power: 4200W/4200VA/6200W/6200VA/10200W/10200VA
Maximum Solar Charging Current: 120A/160A
PV Input(DC): Nominal DC Voltage/Maximum DC Voltage: 360VDC/500VDC; Start-up Voltage/Initial Feeding Voltage: 60VDC/90VDC; 90VDC/120VDC; Maximum DC Voltage: 60VDC~450VDC
Number Of MPPT: 1/18A/1/22A/2/18A
Trachers/Maximum Input Current: GRID OUTPUT(AC): Nominal Output Voltage: 220/230/240VAC; Output Voltage Range: 195.5~253VAC; Nominal Output Current: 18.2A/27.0A/44.3A; Power Factor: >0.99; Feed-in Grid Frequency Range: 49-51Hz

|Victor Eco 4.2kw Plus|Victor Eco 4.2kw|Victor Eco 6.2kw Plus|
**High-Efficiency Power Conversion**
The Victor Eco Series solar inverter is engineered to deliver unparalleled performance with its dual output system, capable of converting solar energy into usable AC power with maximum efficiency of 98%. This cutting-edge technology is perfect for both on-grid and off-grid scenarios, providing reliable power for your home, office, or remote locations. The versatility of the Victor Eco Series is further enhanced by its dual PV input, allowing for greater flexibility in system design and installation.
**Robust and Adaptable Design**
Built to withstand the rigors of various environments, the Victor Eco Series features a robust design with a compact form factor. The Dual Output On/Off-Grid Solar Inverter is available in three models, each tailored to meet different power requirements. The inverter’s dimensions are designed to fit seamlessly into your space, while the cartoon dimensions ensure easy transportation and installation. With a weight ranging from 8.9 to 15 kgs, the inverter is easy to handle and install, ensuring a smooth transition to renewable energy.
**Advanced Features for Optimal Performance**
The Victor Eco Series is not just about power; it’s about intelligent power management. The inverter’s advanced features include a communication port for easy monitoring and control, ensuring that your system is running at peak efficiency. With a maximum AC charging current of 140A, the inverter is capable of supporting a wide range of battery types, including lithium batteries. Whether you’re looking to power your home, business, or off-grid living, the Victor Eco Series is the reliable partner to meet your energy needs.
